Wilwood 120-15702 Electric Parking Brake Floating Mount Caliper Right 1 Piston Polished
Electric Parking Brake
Wilwood’s new Electronic Parking Brake Caliper (EPB), is a high-torque alternative to manual cable actuated brakes. Offering a simplified installation with additional electronic control systems also available from Wilwood. Available in many popular rotor widths 0.157" to 1.25”.
| Pistons | |
|---|---|
| Piston Count | 1 |
| Piston Area (in²) | 0.00 |
| Piston Type | Steel |
| Dust Boot | No |
| Rotor Dimensions | |
| Rotor Width (in) | 1.10 |
| Rotor Diameter(in) | 14.00 |
| Pad Dimensions | |
| Pad Area (in²) | 1.7 |
| Pad Volume (in³) | 0.26 |
| Duty Rating & Material | |
| Material | Aluminium / Steel |
| Weight(Lbs) | 5.0 |
| Colors & Finish | |
| Color | Polished |
| Finish | Polish |
| Mounting | |
|---|---|
| Mount Center(in) | 4.75 |
| Mount Position | |
| Mount Side | Right Hand |
| Mount Type | Lug |
| Rotor Compatibility | |
|---|---|
| Rotor Width (in) | 1.10 |
| Maximum Rotor Width (in) | 1.10 |
| Minimum Rotor Width (in) | 1.04 |
| Maximum Rotor Diameter(in) | 14.00 |
| Minimum Rotor Diameter(in) | 11.00 |
| Piston Specifications | |
|---|---|
| Piston 1 Bore (in) | 1.25 |
| Piston 2 Bore (in) | |
| Piston 3 Bore (in) | |
| Total Piston Area (in²) | 0.00 |
More Information
| Manufacturer | Wilwood |
|---|
